Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector

PART NUMBER: 0891-113
zoom photos Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector
Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector
Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector
Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector
Share this item
share Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector on Facebook share Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector on Twitter share Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector on Pinterest

Schauer JAC1548H | 48v 15 Amp Automatic Smart Charger w/ SB50 Grey Connector

PART NUMBER: 0891-113
Free Ground Shipping to Lower 48 States *
-37% $29995 Currently in Stock
Normal Price: $473.00
Link copied to clipboard
Visa
mastercard
discover
american express
PayPal

OR

  • Continuous 100% duty cycle
  • Optimal 3 Step Charging
  • Built-in Mode Indicators
  • Demand Sensing
  • Reverse Polarity Protection
  • Part Number: 0891-113

icon Important Notice

See accessories below for the specific plug your cart may need. This charger otherwise ships with SB50 style plug shown as pictured.

Overview

The Schauer JAC1548H (part# 0891-113) is a 48v 15 amp fully automatic constant current charger that comes with a SB50 grey connector. Schauer chargers are electronic chargers that charge faster and more accurately than conventional chargers.

The JAC1548H provides an automatic three-stage charging. It starts with the Constant Current charge, switches to a Constant Voltage stage, and then finishes with the Float standby mode. The float charge holds the battery at 100% ready state. The charger can be left on indefinitely without worrying about undercharging or overcharging.

The Schauer charger can be used world wide and accepts and operates on voltage range of 100 to 240 VAC and 50 or 60 Hz. The JAC Series charger will act as a power supply in conjunction with a battery hook up.
Excellent choice for multi battery series of 6 or 12 volt batteries that are used in scissor lifts, golf carts, small fork lifts, etc.

Japlar Schauer is a 50 year old battery charger company headquartered in Blue Ash, Ohio. We at BatteryStuff.com feel the JAC Series chargers offer an excellent value for the money spent. * Flat Rate shipping is for the lower 48 states only.

Features

  • Charger ships with integral 6 foot leads with SB 50 Connector
  • Additional cart specific plug may be necessary for your application. See 'items you may also like'
  • Continuous 100% duty cycle
  • Optimal 3 Step Charging
  • Built-in Mode Indicators
  • Demand Sensing
  • Reverse Polarity Protection
  • Over Voltage Protected
  • Short Circuit Protection
  • Overload Protection
  • Thermal Protection
  • 2 Year Warranty

This Product Replaces These Other Products

JAC1548H-0891-112, 0891-112

Works In

Vehicles that 0891-113 works in

Technical Specifications

  • Dimensions (LxWxH): 11.25 x 7.0 x 6.375 in
  • Weight: 11 lb
  • Max Current, During Bulk Charge: 15 A
  • Absorption Voltage: 59.5 V or 57.6 V
  • AC Input Amps: 13.6 A @ 115 VAC
  • AC Input Volts Freq.: 50/60 Hz
  • AC Input Volts Range: 100 to 240 VAC
  • Float Current: Variable
  • Float Voltage: 53.0 V
  • Dual Fan Speed Cooling: Fast in Bulk & Absorption stages, Slow in Float Mode
  • Enclosure: Aluminum Case
  • Output Banks: 1
  • Regulatory Approval: UL pending
  • Shipping Weight: 12 lb
  • UPC: 078942081135
  • Manufacturer: Japlar Schauer
  • Manufacturer’s Part Number: 0891-113
  • Model: JAC1548H
